Specifications

• Engine

  add remove
  • Cylinders:
    1
  • Horsepower (bhp):
    44
  • Torque (Ft Lbs):
    37
  • Cooling:
    Liquid
  • Displacement (cc):
    580
• TRANSMISSION

  add remove
  • Transmission Type:
    Continuously Variable (CVT)
  • Hi / Low Range:
    Yes
  • Primary Drive (Rear Wheel):
    Shaft
  • Primary Drive (Engine / Transmission):
    Belt
  • Primary Drive (Front Wheel):
    Shaft
• TECHNICAL SPECIFICATIONS

  add remove
  • Width (in):
    46.5
  • Height (in):
    55
  • Wheelbase (in):
    58.5
  • Ground Clearance (in):
    10.6
  • Dry Weight (lbs):
    863
  • Fuel Capacity (gal):
    4.8
  • Engine Displacement to Weight (cc):
    0.67
  • Towing Capacity (lbs):
    1500
  • Turning Radius (ft):
    12.1
• SUSPENSION

  add remove
  • Rear Suspension Type:
    Independent Double A-Arm
  • Number Rear Shock Absorbers:
    2
  • Front Travel (in):
    6.3
  • Rear Travel (in):
    8.3
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    26
  • Rear Tire Diameter (in):
    26
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    12
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    12
  • Front Tire (Full Spec):
    26 x 9 R12
  • Rear Tire (Full Spec):
    26 x 11 R12
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
