Specifications

• Engine

  add remove
  • Cylinders:
    2
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    71
  • Horsepower RPM:
    7000
  • Torque (Ft Lbs):
    54
  • Cooling:
    Liquid
  • Valves:
    8
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Displacement (cc):
    963
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (mm):
    2946.4
  • Width (in):
    63.5
  • Height (in):
    73
  • Wheelbase (in):
    80.7
  • Ground Clearance (in):
    11.4
  • Dry Weight (lbs):
    1537
  • Fuel Capacity (gal):
    10.6
  • Engine Displacement to Weight (cc):
    0.63
  • Towing Capacity (lbs):
    2500
  • Turning Radius (ft):
    13.4
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    27
  • Rear Tire Diameter (in):
    27
  • Tread Type:
    All Terrain
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    CST 27 x 9 - 14
  • Rear Tire (Full Spec):
    CST 27 x 11 - 14
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
