Specifications

• Engine

  add remove
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    36
  • Horsepower RPM:
    6250
  • Torque (Ft Lbs):
    33
  • Cooling:
    Liquid
  • Valves:
    4
  • Valves Per Cylinder:
    4
  • Valve Configuration:
    SOHC
  • Displacement (cc):
    580
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (mm):
    2819.4
  • Width (in):
    57
  • Height (in):
    76
  • Wheelbase (in):
    76
  • Ground Clearance (in):
    10.5
  • Dry Weight (lbs):
    1345
  • Fuel Capacity (gal):
    9.3
  • Engine Displacement to Weight (cc):
    0.43
  • Towing Capacity (lbs):
    1500
  • Turning Radius (ft):
    14.9
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    26
  • Rear Tire Diameter (in):
    26
  • Front Tire Width:
    8
  • Front Wheel Diameter:
    12
  • Rear Tire Width:
    10
  • Rear Wheel Diameter:
    12
  • Front Tire (Full Spec):
    26 x 8 - 12
  • Rear Tire (Full Spec):
    26 x 10 - 12
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
