Specifications

• Engine

  add remove
  • Cylinders:
    3
  • Engine Stroke:
    4-Stroke
  • Horsepower (bhp):
    88
  • Horsepower RPM:
    7250
  • Torque (Ft Lbs):
    69
  • Cooling:
    Liquid
  • Valve Configuration:
    DOHC
  • Displacement (cc):
    998
• TECHNICAL SPECIFICATIONS

  add remove
  • Length (mm):
    3759.2
  • Width (in):
    64
  • Height (in):
    77
  • Wheelbase (in):
    112.5
  • Ground Clearance (in):
    13
  • Dry Weight (lbs):
    2374
  • Fuel Capacity (gal):
    11.8
  • Towing Capacity (lbs):
    2500
  • Turning Radius (ft):
    17.7
• WHEELS & TIRES

  add remove
  • Front Tire Diameter (in):
    29
  • Rear Tire Diameter (in):
    29
  • Tread Type:
    All Terrain
  • Front Tire Width:
    9
  • Front Wheel Diameter:
    14
  • Rear Tire Width:
    11
  • Rear Wheel Diameter:
    14
  • Front Tire (Full Spec):
    CST 29 x 9 - 14
  • Rear Tire (Full Spec):
    CST 29 x 11 - 14
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Rear Brake Type:
    Hydraulic Disc
